TECHNICAL FEATURES
Amplifier (program power) | 1000 W – Class D |
Input Sensitivity | 2 dBu – 1 V |
Input Impedance | 20 KΩ Balanced |
Maximum input level | 20 dBu |
Mains | Universal switch mode Power Supply 85-265 V / 45-65 Hz |
Average current draw | 1 A (Heavy duty musical program) |
SPL (1m) | 127 dB continuous, 130 dB peak |
Built-in DSP | 48 bit |
Presets | XOPOLE / LPF90 / LPF90+3 / LPF100 / LPF100+3 / LPF120 / LPF120+3 |
AD/DA converters | 24 bit – 48 kHz |
Standby mode consumption | < 5 W |
Adjustable Delay line | 118 ms / 40 m |
Frequency response (-10 dB) | 36 Hz – 90/100/120 Hz |
Components: | |
LF | 15” woofer (4” voice coil) |
Directivity (HxV) | omnidirectional |
Dimensions (HxWxD) | 475 x 630 x 630 mm |
Weight | 41.6 kg |
Finish | Multilayer plywood |
