PG58 with SVX2 Wireless Handheld Transmitter
Features:
RF Level Switch between 1mW and 10mW
2 “AA” batteries
Up to 10 hours of battery life
Bottom on/off switch design
Anti-rolling ring on grille for PG28
Power and battery status LED
6 color rings for microphone identification
SVX88 Dual Channel Diversity Receiver
Further Technical Specs
Dimensions: 32 mm X 168 mm X 104.5 mm (1.26 in. x 6.625 in. x 4.2 in.)
Weight: 245 g (11.5 oz.)
Housing: Molded ABS
Audio Output Level (Ref. ±48 kHz deviation with 1 kHz tone):
XLR connector into 100 kΩ load: -16 dBV (MIC)
6.35 mm (1/4”) connector into 100 kΩ load: -22 dBV (MIC)
Output Impedance:
XLR connector: 600 Ω
6.35 mm (1/4”) connector: 600 Ω
Sensitivity: –105 dBm for 12 dB SINAD, typical
Image Rejection: >50 dBm, typical
Power Requirements: 12 to 18 V DC @ 130 mA, supplied by external power supply
